38
Masking Systems
3M
TM
Trim Masking Tape
3M
TM
Soft Edge Foam Masking Tape
3M Trim Masking Tape is designed to lift mouldings, allowing complete paint coverage under the
moulding while protecting the front of the moulding from paint overspray. The hard band fits under the
moulding and the tape pulls the moulding away from the substrate. 3M Trim Masking Tape eliminates
sharp paint edges, speeds vehicle painting and improves vehicle throughput.
A three dimensional, foam tape designed to be used in masking
door jambs, bonnet, boot openings and other areas of a vehicle
which need to be sealed during painting. Provides a “soft edge”
to prevent tape lines in these jamb areas.
Product
No.
Description
Tape Structure
Widths mm
Total
Thickness
Adhesion
to steel
Maximum
Temp
Backing
Adhesive
6345
3M Trim
Masking Tape
Plastic
Linered
5mm hard
board x 50mm
Tape - 3mm
Film - 9mm
53N/100mm 121°C
6347
7mm hard
board x 50mm
6349
10mm hard
board x 50mm
6348
15mm hard
board x 50mm
Product
No.
Description
Tape Structure
Widths mm
Total
Thickness
Adhesion
to steel
Maximum
Temp
Backing
Adhesive
6293
Soft Edge Foam
Masking Tape PLUS
Foam
Rubber
21mm
-
-
77°C
6297
Soft Edge Foam
Masking Tape
Foam
Rubber
13mm
Approx 12mm -
77°C
